PCB rapid prototyping set

The set is comprised of instruments for fast prototyping of small quantities of printed circuit boards via classical (“wet”) photo-chemical process. It allows production of two-layer through-hole-plated boards up to 6th precision class according to IPC-A600D standard. Specifically, the set contains these instruments:

-Double-sided PCB cleaning/brushing machine Bungard RBM 402 KF
-CNC PCB drill/plotter LPKF ProtoMat H100
-Dry film laminator Bungard RLM 419p
-CNC UV laser direct imaging system Bungard Direct Laser
-Conveyorised spray developing machine Bungard DL 500
-Conveyorised spray etching machine Bungard DL 500
-Conveyorised spray stripping machine Bungard DL 500-S
-Through hole copper plating system Bungard Profi 3045
-Bechtop automatic film processor Colenta Mediphot 900E
-Double-sided parallel UV exposure unit Bungard EXP 8000
